Ceiling Mounts are usually picked by the customers who prefer their TV folded or space saving for the room. Now, via Remote/Tuya App/Voice Control, the PLB-M0546S mounts can swivel up to 180° for multiple viewing angles. Quality motor holds TVs up to 75″ (35kg/77lbs) and provides automatic flip up and down function with the press of a button. A balanced mechanism prevents any ceiling vibrations when the TV is in motion. Collision avoidance system stops swiveling the TV when there are any obstacles. Keyhole pattern allows for easy installation and height-adjustment. This mount can be installed on cement or other solid surfaces. Perfect choice for public or home TV viewing installations!
| Product Category: |
Motorized TV Ceiling Mount |
| Rank: |
Standard |
| Material: |
Steel,Plastic |
| Metal Sheet Thickness: |
Bracket Arm THK=2mm cold-rolled sheet,VESA Panel THK=2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet (VESA Panel THK=0.079″ cold-rolled sheet,Wall Plate THK=0.079″ cold-rolled sheet,Bracket Arm THK=0.079″ cold-rolled sheet) |
| Surface Finish: |
Powder Coating |
| Color: |
Matte Black |
| Color(accessory): |
Matte Black |
| Dimensions: |
750x664x516mm (29.5″x26.1″x20.3″) |
| Fit Screen Size: |
32″-75″ |
| Fit Curved TV: |
Yes |
| Mounting Hole Pattern: |
VESA Only |
| VESA Compatible: |
200×100,200×200,300×200,200×400,400×200,300×300,400×300,400×400,600×400 |
| Max. Mounting Hole: |
600×400 |
| Weight Capacity: |
35kg (77lbs) |
| Strength Tested: |
3 Times Approved |
| Profile: |
140mm (5.5″) |
| Tilt Range: |
0~-75° |
| Swivel Range: |
+90°~-90° |
| Screen Level: |
+2°~-2° |
| Screen Freely Tilting: |
No |
| Installation: |
Ceiling Mounted |
| Panel Type: |
Detachable Panel |
| Wall Plate Type: |
Fixed Wall Plate |
| AV Component Shelf: |
No |
| Cable Management: |
Yes |
| Anti-theft: |
No |
| Power Supply: |
Input:AC 100~240V,50/60Hz;Output:DC 24V, 1.5A |
| Power Cord Length: |
3m (9.8ft) |
| Controller Type: |
Application Control,Radio Frequency(RF) Remote |
| Bubble Level: |
No |
| Accessory Kit Package: |
Normal/Ziplock Polybag,Compartment Polybag |
| Certification: |
CE,ErP,FCC,RoHS,UKCA |
