PLB-M0546AI SMART FLIP DOWN TV CEILING MOUNT powered by Tuya

Experience the future of home entertainment with smart voice and APP control! LUMI’s PLB-M0546AI Smart Flip Down TV Ceiling Mount is a perfect choice to save space or for room with low ceiling. A quality motor holds TVs up to 32″ ~ 70″ and lowers and retracts TVs smoothly and quietly. A balanced mechanism prevents any ceiling vibrations when the TV is in motion. There are convenient memory settings as well — a brilliant choice for public or home TV viewing installations!

Product Category:	Motorized TV Ceiling Mount
Rank:	Standard
Material:	Steel,Plastic
Metal Sheet Thickness:	Bracket Arm THK=2mm cold-rolled sheet,VESA Panel THK=2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet (VESA Panel THK=0.079″ cold-rolled sheet,Wall Plate THK=0.079″ cold-rolled sheet,Bracket Arm THK=0.079″ cold-rolled sheet)
Surface Finish:	Powder Coating
Color:	Matte Black,Matte White
Dimensions:	725x664x516mm (28.5″x26.1″x20.3″)
Fit Screen Size:	32″-70″
Fit Curved TV:	Yes
Mounting Hole Pattern:	VESA Only
VESA Compatible:	200×100,200×200,300×200,200×400,400×200,300×300,400×300,400×400,600×400
Max. Mounting Hole:	600×400
Weight Capacity:	35kg (77lbs)
Strength Tested:	3 Times Approved
Profile:	108mm (4.3″)

Tilt Range:	0~-75°
Screen Level:	+2°~-2°
Screen Freely Tilting:	No
Installation:	Ceiling Mounted
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
AV Component Shelf:	No
Cable Management:	Yes
Anti-theft:	No
Power Supply:	Input:AC 100~240V,50/60Hz;Output:DC 24V, 1.5A
Power Cord Length:	1.5m (4.9ft)
Controller Type:	Application Control,Radio Frequency(RF) Remote
Bubble Level:	No
Accessory Kit Package:	Normal/Ziplock Polybag,Compartment Polybag
Certification:	CE,ErP,FCC,RoHS
